Specifications
| CPU Support | AMD EPYC 7003 Series Processors, AMD EPYC 7002 Series Processors |
| Memory Type | DDR4 RDIMM, LRDIMM, RDIMM/LRDIMM-3DS, NVDIMM-N |
| LAN Controller | Intel X710-AT2, Realtek RTL8211E |
| Form Factor | Micro-ATX |
| Socket Count | 1 |
| Maximum TDP Support | 280W |
| Dimensions | 9.6" x 9.6" (244 mm x 244 mm) |
| Rated Voltage | 1.2V |
| Socket Type | Socket SP3 (LGA 4094) |
| Chipset | System on Chip |
| Number of Memory Slots | 8 |
| Memory Speed | Up to 3200 MT/s |
| LAN Ports | 2x 10Gb/s RJ45 (Intel X710-AT2); 1x 1Gb/s RJ45 (Realtek RTL8211E) for dedicated management |
| Onboard Graphics | ASPEED AST2500 |
| PCIe Expansion Slots | SLOT6: PCIe 4.0 x16; SLOT5: PCIe 4.0 x16; SLOT4: PCIe 4.0 x16 |
| M.2 Slots | 1x M.2 (2280/22110) PCIe 4.0 x4 or SATA 6Gb/s |
| Storage Interface | 2x Mini-SAS HD (8x SATA 6Gb/s or 2x PCIe 4.0 x8); 2x SlimSAS (2x PCIe 4.0 x8); 2x SATA 6Gb/s |
| Power Connectors | 2x 8-pin ATX 12V power connectors; 1x 4-pin ATX 12V power connector |
| Fan Headers | 6x 4-pin fan headers |
| USB Internal Headers | 1x USB 3.2 Gen1 x2 header |
| Rear USB Ports | 2x USB 3.2 Gen1 |
| Serial Port | 1x COM header |
| TPM | 1x 13-pin TPM header (SPI); 1x 17-pin TPM header (LPC) |
| BMC | ASPEED AST2500 |
| Operating Temperature | 10°C to 35°C (50°F to 95°F) |
| Non-Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Video Resolution | VGA |
| Maximum Memory Capacity | RDIMM: 512GB (64GB per DIMM); LRDIMM: 1024GB (128GB per DIMM); RDIMM/LRDIMM-3DS: 2048GB (256GB per DIMM); NVDIMM-N: 256GB (32GB per DIMM) |
