Specifications
| CPU Support | AMD EPYC 7003 Series Processors, AMD EPYC 7002 Series Processors |
| Form Factor | EEB (12" x 13", 305mm x 330mm) |
| Socket Count | 1 |
| Dimensions | 305 x 330 mm (12" x 13") |
| Weight | Net: 1.4 kg; Gross: 2.5 kg |
| Socket Type | Socket SP3 (LGA 4094) |
| Memory Type | DDR4 3200/2933/2666 RDIMM/LRDIMM/LRDIMM 3DS |
| Memory Channels | 8 |
| Number of Memory Slots | 16 |
| Memory Speed | DDR4-3200/2933/2666 MHz |
| LAN Controller | Intel I350-AM2 |
| LAN Ports | 2x 1Gb/s RJ45; 1x Management Port |
| Onboard Graphics | ASPEED AST2500 64MB |
| PCIe Expansion Slots | Slot 2: PCIe 3.0 x16 (x16 link) FL; Slot 3: PCIe 3.0 x16 (x16 link, if Slot 3 occupied switches to x8 link) FL; Slot 4: PCIe 3.0 x8 (x8 link q-switch from slot-2) HL; Slot 5: PCIe 4.0 x8 (x8 link) HL; Slot 6: PCIe 4.0 x24 (x16 link + x8 link) HL; OCP 2.0 Mezzanine card (x16 link) |
| Storage Interface | 4 x SATA3 6Gb/s ports; 12 x SATA3 6Gb/s ports by 3 Mini-SAS HD connectors; 6 x OCuLink ports (Gen3 x4 link); 1 x M.2 connector (2242/2260/2280/22110) both SATA & PCIe mode |
| Power Connectors | 1x 24-pin ATX main power connector; 2x 8-pin ATX 12V power connectors |
| Fan Headers | 8x chassis fan connectors |
| USB Internal Headers | 1x USB 3.0 header (front panel) |
| Rear USB Ports | 2x USB 3.0 |
| Serial Port | 1x COM |
| TPM | 1x TPM header with SPI interface |
| BMC | ASPEED AST2500 |
| Front Panel Header | 1x Front panel header |
| Backplane Board Header | 1x Backplane board header |
| PMBus Connector | 1x PMBus connector |
| IPMB Connector | 1x IPMB connector |
| Operating Temperature | 10°C to 35°C |
| Non-Operating Temperature | -40°C to 70°C |
| Management Features | ASUS Control Center (Classic); ASMB9-iKVM with KVM-over-IP; ASUS Thermal Radar 2.0 technology |
| Non-Operating Humidity | 20% to 90% (non-condensing) |
| Video Resolution | 1920x1200@60Hz 32bpp |
| Maximum Memory Capacity | 2TB (2048GB) RDIMM |
| Supported Memory Densities | 32GB, 16GB, 8GB (RDIMM); 64GB, 32GB (LRDIMM); 128GB, 64GB (LRDIMM 3DS) |
| Total PCIe Slots | 5+1 (5 PCIe slots + 1 OCP 2.0) |
| Remote Management | ASMB9-iKVM out-of-band KVM-over-IP |
| SAS Controller Support | Optional ASUS PIKE II 3108-8i-240 PD 2G SAS HW RAID card supporting SAS 12Gbps |
