Specifications
| Form Factor | 1U, ATX (12" x 9.6"), 1U Single or 1U 1+1 Redundant |
| Compatible Drive Type | SATA, SAS |
| Dimensions | 547.6 x 438.5 x 43.5 mm (21.56" x 17.26" x 1.71") |
| Fan Dimension | 40 x 28 mm |
| Rear USB Ports | 2x USB 3.0 |
| Number of Fans | 3 |
| Number of Drives | 10 |
| Drive Bay | 10 x 2.5" Hot-swap |
| Support Drive Size | 2.5" |
| Host Interface | Mini-SAS HD |
| Support Hot-Swap | Yes |
| Package Net Weight | 7.5 kg |
| Storage Backplane | 2.5" 10-port 12Gbps Mini-SAS HD |
| Cooling Fan | 3 x 40mm (28mm thickness), up to 6 |
| Gross Weight | 10.0 kg |
| Expansion Slot Opening | 1 x Full Height & Half Length |
| Front Control | 1 x Power On/Off; 1 x UID; 2 x USB3.0 |
