Power Consumption
|
At Duty Cycle 20%: 0.60 W,
At Duty Cycle 50%: 1.44 W,
At Duty Cycle 100%: 9.60 W
|
|
Air Flow
|
At Duty Cycle 20%: 3.533 CFM,
At Duty Cycle 50%: 7.645 CFM,
At Duty Cycle 100%: 14.719 CFM
|
|
Noise Level
|
At Duty Cycle 20%: 20.71 dBA,
At Duty Cycle 50%: 37.5 dBA,
At Duty Cycle 100%: 51.7 dBA
|
|
Static Pressure
|
At Duty Cycle 20%: 2.083 mm-H2O,
At Duty Cycle 50%: 9.780 mm-H2O,
At Duty Cycle 100%: 36.168 mm-H2O
|
|
Lead Wire Pin Out
|
Pin1-Black (-),
Pin2-Yellow (+),
Pin4-Blue (PWM),
Pin3-Green (Techometer/Signal output)
|
|
Power Connector
|
4-pin PWM
|
|
Form Factor
|
1U Server
|
|
CPU Socket
|
LGA1200/115X
|
|
CPU Support
|
Intel
|
|
Maximum TDP Support
|
125W
|
|
Heatsink Material
|
Copper Heatsink with Skiving Fins
|
|
Dimensions
|
85.0 x 81.5 x 28.5 mm
|
|
Weight
|
355g ± 5g
|
|
Fan Dimension
|
Ø80.0 x 15.0 mm
|
|
Fan Speed
|
“20% @ 1200, 50% @ 2600, 100% @ 5000”
|
|
Bearing Type
|
2 Ball Bearing
|
|
Rated Voltage
|
12V
|
|
Fan Life Expectancy
|
70,000 Hours
|
|
Screw Type
|
M3
|
|
Installation Torque
|
5-7 in-lb
|
