Power Consumption
|
At Duty Cycle 0~20%: 1.20 W,
At Duty Cycle 50%: 2.28 W,
At Duty Cycle 100%: 7.20 W
|
|
Fan Speed
|
At Duty Cycle 20%: 1600±200 RPM,
At Duty Cycle 50%: 4000±10% RPM,
At Duty Cycle 100%: 8000-0/+500 RPM
|
|
Air Flow
|
At Duty Cycle 0~20%: 9.28 CFM,
At Duty Cycle 50%: 23.21 CFM,
At Duty Cycle 100%: 46.41 CFM
|
|
Noise Level
|
At Duty Cycle 0~20%: 18 dBA,
At Duty Cycle 50%: 37.89 dBA,
At Duty Cycle 100%: 52.94 dBA
|
|
Static Pressure
|
At Duty Cycle 0~20%: 0.76 mm-H2O,
At Duty Cycle 50%: 4.76 mm-H2O,
At Duty Cycle 100%: 19.04 mm-H2O
|
|
Lead Wire Pin Out
|
Pin1- (-),
Pin2- (+),
Pin3- (Techometer/Signal output),
Pin4- (PWM)
|
|
Power Connector
|
4-pin PWM
|
|
Form Factor
|
2U Server
|
|
CPU Socket
|
LGA 1150/1151/1155/1156/1200
|
|
CPU Support
|
Intel
|
|
Maximum TDP Support
|
125W
|
|
Heatsink Material
|
Copper Base & Aluminum Fins with Heat Pipe embedded
|
|
Dimensions
|
90.7 x 85.0 x 64.0 mm
|
|
Weight
|
500 g
|
|
Fan Dimension
|
60 x 60 x 25 mm
|
|
Bearing Type
|
2 Ball Bearing
|
|
Rated Voltage
|
12V
|
|
Fan Life Expectancy
|
70,000 Hours (continuous operating under normal temperature 40°C or 104°F)
|
|
Screw Type
|
M3
|
|
Installation Torque
|
5-7 in-lb
|
|
Thermal Compound
|
Shin-Etsu 7762
|
