Power Consumption
|
At Duty Cycle 50%: 1.44 W,
At Duty Cycle 100%: 9.60 W,
At Duty Cycle 0-20%: 0.60 W
|
|
Fan Speed
|
At Duty Cycle 0-20%: 800 RPM,
At Duty Cycle 50%: 1500 RPM,
At Duty Cycle 100%: 3000 RPM
|
|
Air Flow
|
At Duty Cycle 0-20%: 13.67 CFM,
At Duty Cycle 50%: 25.63 CFM,
At Duty Cycle 100%: 51.26 CFM
|
|
Noise Level
|
At Duty Cycle 0-20%: 13.45 dBA,
At Duty Cycle 50%: 27.1 dBA,
At Duty Cycle 100%: 42.15 dBA
|
|
Static Pressure
|
At Duty Cycle 0-20%: 0.402 mm-H2O,
At Duty Cycle 50%: 1.41 mm-H2O,
At Duty Cycle 100%: 5.66 mm-H2O
|
|
Power Connector
|
4-pin PWM
|
|
Form Factor
|
3U Server
|
|
CPU Support
|
Intel
|
|
Maximum TDP Support
|
270W
|
|
Heatsink Material
|
Aluminum Stacked-fin with Heat Pipes directly contact CPU
|
|
Dimensions
|
128 x 91 x 110 mm
|
|
Weight
|
600 g
|
|
Fan Dimension
|
80 x 80 x 38 mm
|
|
Bearing Type
|
Two-Ball Bearing
|
|
Rated Voltage
|
12V
|
|
Socket Type
|
FCLGA4189-4/5 (Socket P4/P5)
|
|
Thermal Compound
|
Shin-Etsu 7762 Pre-Applied
|
