Specifications
| CPU Support | AMD EPYC 7003 Series Processors, AMD EPYC 7002 Series Processors |
| Form Factor | E-ATX |
| Socket Count | 2 |
| Maximum TDP Support | 280W |
| Dimensions | 305 x 330 mm |
| Socket Type | Socket SP3 (LGA 4094) |
| Chipset | System on Chip |
| Memory Type | DDR4 RDIMM/LRDIMM |
| Memory Channels | 8 |
| Number of Memory Slots | 16 |
| Memory Speed | Up to 3200 MT/s |
| LAN Controller | Broadcom BCM57416 |
| LAN Ports | 2x 10Gb/s RJ45; 1x 10/100/1000 Mbps Management LAN |
| NCSI Support | Yes |
| Onboard Graphics | ASPEED AST2600 |
| PCIe Expansion Slots | Slot_6: PCIe x16 (Gen4 x16) from CPU_0; Slot_4: PCIe x16 (Gen4 x16) from CPU_0; Slot_3: PCIe x16 (Gen4 x16) from CPU_1; Slot_2: PCIe x16 (Gen4 x8) from CPU_0; Slot_1: PCIe x16 (Gen4 x8) from CPU_1 |
| M.2 Slots | 1x M.2 (2280/22110) PCIe Gen4 x4 from CPU_0 |
| Storage Interface | 3x SlimSAS 4i for 3x Gen4 NVMe or 12x SATA 6Gb/s from CPU_1; 2x SlimSAS 4i for 2x Gen4 NVMe from CPU_0; 4x SATA 6Gb/s 7-pin from CPU_0 |
| Power Connectors | 1x 24-pin ATX main power connector; 2x 8-pin ATX 12V power connectors |
| Fan Headers | 2x CPU fan headers; 4x System fan headers |
| USB Internal Headers | 2x USB 3.0 headers; 2x USB 2.0 headers |
| Rear USB Ports | 2x USB 3.0 |
| Serial Port | 1x COM |
| TPM | 1x TPM 2.0 13-pin Header |
| BMC | ASPEED AST2600 |
| Video Resolution | 1920x1200@60Hz 32bpp |
| Maximum Memory Capacity | 4 TB |
| Supported Memory Densities | RDIMM up to 128GB; LRDIMM up to 256GB (3DS) |
| Remote Management | IPMI |
| Video Output | VGA |
| Dedicated Video Memory | 512 MB DDR4 SDRAM |
| BIOS Type | AMI |
