Specifications
| Power Connector | 24-pin, 8-pin |
| M.2 Slots | 1, PCIe 3.0 x4; SATA 6Gb/s |
| Fan Headers | 1, 2 |
| Rear USB Ports | 2 (Type-A), 4 |
| Form Factor | Micro-ATX |
| CPU Socket | LGA 1700 |
| Chipset | Intel H610 |
| Memory Type | DDR4 |
| Memory Channels | Dual |
| Number of Memory Slots | 2 |
| Memory Speed | 3200MHz (Max) |
| Maximum Memory Capacity | 64GB |
| Processor Support | Intel Core 14th Gen; Intel Core 13th Gen; Intel Core 12th Gen; Intel Pentium Gold; Intel Celeron |
| PCIe x16 Slots | 1 |
| PCIe x16 Version | PCIe 4.0 |
| PCIe x1 Slots | 1 |
| PCIe x1 Version | PCIe 3.0 |
| SATA Ports | 4 |
| SATA Version | 6Gb/s |
| M.2 Size Support | 2280; 2260; 2242 |
| Audio Chipset | Realtek ALC897 |
| Audio Channels | 7.1 |
| LAN Chipset | Realtek RTL8111H |
| LAN Speed | Gigabit (1Gbps) |
| USB 3.2 Gen 1 Front Headers | 2 (Type-A) |
| USB 2.0 Front Headers | 4 |
| Video Outputs | HDMI 1.4; VGA |
| HDMI Resolution | 4K@30Hz |
| VGA Resolution | 2048x1536@50Hz; 2048x1280@60Hz; 1920x1200@60Hz |
| Operating System Support | Windows 11 64-bit; Windows 10 64-bit |
| TPM Header | Yes (TPM 2.0) |
| RGB LED Header | Yes |
| Board Dimensions | 23.6 cm x 20 cm (9.3 in x 7.9 in) |
