MZ32-AR0 Server Motherboard

MZ32-AR0 Server Motherboard

Professional AMD EPYC server motherboard designed for enterprise workloads. The MZ32-AR0 features single-socket SP3 design supporting AMD EPYC 7003/7002/7001 Series processors with up to 64 cores and 280W TDP. Equipped with 8-channel DDR4 architecture supporting 16 DIMM slots for massive memory capacity, dual Intel I350-AM2 Gigabit Ethernet ports, and comprehensive storage connectivity including 4x SlimSAS NVMe, 2x SlimSAS SATA, and 2x M.2 PCIe Gen3 x4 slots. Expansion capabilities include 5x PCIe Gen4 slots, 2x PCIe Gen3 slots, and an OCP 2.0 mezzanine slot. Features ASPEED AST2500 remote management controller with dedicated management LAN for enterprise-grade IPMI functionality and remote administration.
₹ 1.00 ₹ 1.00
₹ 1.00

  • Display Connectors
  • Form Factor
  • CPU Socket
  • Socket Count
  • CPU Support
  • Maximum TDP Support
  • Dimensions
  • Chipset
  • Memory Type
  • Memory Channels
  • Number of Memory Slots
  • Memory Speed
  • LAN Controller
  • LAN Ports
  • NCSI Support
  • Onboard Graphics
  • PCIe Expansion Slots
  • M.2 Slots
  • Storage Interface
  • Fan Headers
  • USB Internal Headers
  • Rear USB Ports
  • Serial Port
  • TPM
  • BMC
  • Front Panel Header
  • Backplane Board Header
  • PMBus Connector
  • IPMB Connector
  • Management Features
  • Video Resolution
  • Package Contents Retail
  • Package Contents Bulk
Add to cart
Add to wishlist
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days
Contact Us

Specifications

CPU Support AMD EPYC 7003 Series Processors, AMD EPYC 7002 Series Processors, AMD EPYC 7001 Series Processors
Memory Speed AMD EPYC 7003 (1DPC): Up to 3200 MT/s, AMD EPYC 7003 (1DPC): Up to 2933 MT/s, AMD EPYC 7002 (1DPC): Up to 3200 MT/s, AMD EPYC 7002 (1DPC): Up to 2933 MT/s
LAN Ports 1x 10/100/1000 Mbps Management LAN, 2x 1Gb/s RJ45
PCIe Expansion Slots Slot_7: PCIe x16 (Gen4 x16) shared with 4x NVMe, Slot_6: PCIe x16 (Gen4 x16), Slot_5: PCIe x16 (Gen4 x8), Slot_4: PCIe x16 (Gen4 x16), Slot_3: PCIe x16 (Gen4 x16), Slot_2: PCIe x8 (Gen3 x0 or x8), Slot_1: PCIe x16 (Gen3 x16 or x8) shared with Slot_2, 1x OCP 2.0 mezzanine (Gen3 x16)
Storage Interface 2x SlimSAS 4i for 8x SATA 6Gb/s, 4x SlimSAS 4i for 4x Gen4 NVMe (Rev 3.x), 4x SlimSAS 4i for 4x Gen3 NVMe (Rev 1.x)
Package Contents Retail 1x MZ32-AR0, 1x I/O shield, 1x Quick start guide, 2x SlimSAS 4i to 4x SATA cables (600mm)
Package Contents Bulk 10x MZ32-AR0, 10x I/O shields
Display Connectors 1x VGA
Form Factor E-ATX
CPU Socket Socket SP3
Socket Count 1
Maximum TDP Support 280W
Dimensions 305 x 330 mm
Chipset System on Chip
Memory Type DDR4 RDIMM/LRDIMM
Memory Channels 8
Number of Memory Slots 16
LAN Controller Intel I350-AM2
NCSI Support Yes
Onboard Graphics ASPEED AST2500
M.2 Slots 2x M.2 (2242/2260/2280) PCIe Gen3 x4
Fan Headers 1x CPU fan header
USB Internal Headers 1x USB 2.0 header
Rear USB Ports 3x USB 3.0
Serial Port 1x COM
TPM 1x TPM header with SPI interface (Optional TPM2.0 kit: CTM010)
BMC ASPEED AST2500
Front Panel Header 1x Front panel header
Backplane Board Header 1x HDD back plane board header
PMBus Connector 1x PMBus connector
IPMB Connector 1x IPMB connector
Management Features GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Video Resolution 1920x1200@60Hz 32bpp
